    Automatic Exercise Book Production Line From A To Z Energy Saving

    Ask Lasest Price
    Brand Name : CWH
    Model Number : AFPS-1040PS
    Certification : CE
    Price : negotiable
    Payment Terms : L/C, T/T
    Delivery Time : 30-45 working days
    • Product Details
    • Company Profile

    Automatic Exercise Book Production Line From A To Z Energy Saving

    Automatic Exercise Book Notebook Production Line From A To Z


    ★Machine brief introduction★


    The main machines adopts synchronized servo motor, achieving at individual usage or online usage.

    With the servo system, it is easy to change parameters by setting on the screen, such as sheets number.

    High efficiency, easy operation, lower producing cost.




    ★Technical parameters★



    Automatic Book Producion Line,
    for staple pin exercise books, central sewn books,
    ModelAFPS-1040PS
    Max. reel diameter1200mm
    Paper width700-1050mm
    Printing color2/2 (two colors on both sides)
    Printing-cutting length350-660mm
    Max. ruling width1040mm
    Cutting length260-660mm
    Max. machine running speed350m/min (depend on paper GSM and quality)
    Number of sheets per group6-50sheets
    Paper sheet width260-660mm
    Paper sheet length700-1050mm
    Stitching head quantity8pcs
    Max. stitching thickness5mm
    Notebook binding length700-1050mm
    Notebook binding width130-300mm
    Side trimming length120-300mm
    Cutting thickness2-10mm
    Power require60KW, 380V, 3phases
    (depend on user's power require)





    ★Photos and Documents★
    Automatic Exercise Book Production Line From A To Z Energy SavingAutomatic Exercise Book Production Line From A To Z Energy Saving
    ★About us★

    Established in 1995,Cheung Wo Hing Printing Machinery Co.,Ltd(CWH)is a large-operated company based on Hong Kong,lt concentrates on R & D,manufacturing,marketing,and professional printing machinery.CWH takes "Based in China Viewing the world"as its long-term developing strategic objective.For more than 20 years.CWH has been commiting production-line which is used for notebook manufacturing related machinery.CWH has also been an agent in China for some of advanced Printing machinery and equipment manufactured at home and abraod.They are highly appreciated and well accepted by the same industry in domestic and international users for their advanced design,stable and outstanding performance.
