    Non - Woven Fabric 5 Layers 0.8Mpa KN95 Mask Production Line

    Ask Lasest Price
    Brand Name : CWH
    Model Number : LXS-95
    Certification : CE
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 20 sets / month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Non - Woven Fabric 5 Layers 0.8Mpa KN95 Mask Production Line

    14 KW Fully automatic 5 layers KN95 mask making machine


    Machine Overview



    Based on CWH MACHINERY's technical experience. the LXS-95 machine is scientifically designed with high-quality imported machinery and electrical components to ensure it runs stably, works efficiently, safely and durable.


    It is using for manufacturing of KN95 mask, with the functions of automatic forming through coil feeding, automatic feeding, cut off of nose bridge strips and coils, cut off edges of the mask, folding and flattening, ultrasonic welding fusion, molding, automated ultrasonic welding ears belts.


    Machine Application



    The technique process of this equipment is suitable for the production of KN95 mask. Common KN95 or N95 mask is mainly composed of 4-5 layers of non-woven fabric :


    The inner layer is ordinary non-woven fabric.


    The outer layer is water-repellent non-woven fabric, which is mainly used to isolate people’s saliva droplets.


    The middle filter layer (1 or 2 layers) is treated polypropylene melt-blown non-woven fabric.


    The other layer of fabric is hot air cotton.


    Machine Features



    (1) High stability, low failure rate, beautiful and solid aluminum alloy structure, not rusty.


    (2) Computer PLC programming control and servo drive.


    (3) The whole machine adopts automatic operation from feeding to finished products.


    (4) Ultrasonic welding technology, high efficiency and energy saving.


    (5) Sensor detection and automatic counting function.


    (6) High capacity: Max 60 per min, Max daily capacity 72000pcs (20 hours)


    (7) Service: convinient equipment maintainance and prompt online service.


    (8) Performance: Stable production in customer and Longxingsheng mask factory.


    Machine Specification


    Model

    LXS-95

    Working speed

    40-60pcs/min

    Power supply

    220V, 50HZ, 14KW

    Air supply

    40l/min, 0.8Mpa

    Layers of cloth

    Max. 5 layers

    Machine weight

    1300KG

    Machine dimension

    9600 x 1750 x 1850mm


    Machine Specification



    Non - Woven Fabric 5 Layers 0.8Mpa KN95 Mask Production Line
